Microcomputer Bursting Ring Crush Strength Testing Machine Cardboard Thickness Test Tools

Name: Microcomputer Bursting Ring Crush Strength Testing Machine Cardboard Thickness Test Tools
Brand: Lycorrugated
Price: 1 USD

Brand Name : Lycorrugated

Model Number : 3000

Certification : CPA，CE，SGS，TUV

Place of Origin : Guangdong,China

MOQ : 1 Set

Price : Factory Wholesale Price

Payment Terms : T/T, Western Union, Paypal

Supply Ability : 1000 Sets Per Month

Delivery Time : 7-15 Days

Packaging Details : Carton

Power : Electronic

BST Measuring Range : (250~5600) kPa

Crush Measuring Range : 60-3000N

Thickness Measuring Range : 0.01-60mm

Accuracy : ±0.5%FS / 0.005mm

BST Speed : (175 ±15)ml/min

Contact Now

Cardboard Thickness Test Tools Microcomputer Bursting Ring Crush Strength Testing Machine

Product Parameter:

Items		Specifications
		BST		Crush	Thickness
Measuring Range		(250～5600)kPa		60-3000N	0.01-60mm
Resolution		1kPa		0.1N	0.001mm
Units		Kgf/cm²,Lb/in²,kPa		KgfNLbf	mm
Accuracy		±0.5%FS			0.005mm
Speed		(175 ±15)ml/min		12.5MM/min
film resistance	Rise high	10mm	18mm	Measuring high:0.01- 60MM
	Resistance value	(170～220)kPa	(250～350)kPa	Platen size:Φ120MM
Clamp pressure)		＞1000kPa		(Platen parallelism):<0.05mm
Weight		≈65kg

Function:

A new unique type of universal testing equipment which can be suitable for paperboard and box products, have many functions which can measure the pop strength, thickness, ring crush strength, edge crush strength, bond strength and flat crush strength of the body paper and paperboard very well

Microcomputer Bursting Ring Crush Strength Testing Machine Cardboard Thickness Test Tools
